SAAS Seats are best fitted in conjunction with either of the following components:
The process of putting a new seat in your vehicle requires a custom subframe (providing an attachment point to the vehicle floor). We recommended you consult an approved engineer to fabricate mounting brackets - accredited engineers can also supply you with a seating label which reflects the new seating arrangements.
| Subframe Mounts | 345mm (W) x 275mm (D) |
| Mounting Boss | 4 x M8x1.25 |
| ADR Compliance | ADR 3/03 - Seat and Seat Anchorages 2009 |
| Seat and Anchorage Longitudinal 20g Test | ADR 3/03 5.5.1.1 & 5.5.2 |
| Rearward Backrest Test | ADR 3/03 5.5. 3 |
| Energy Dissipation Test | ADR 3/03 6.4 |
| Head Restraint Test | ADR 22/00 |
| SKU | RP1002 |
| Barcode | 9348391005268 |
| Length | 1080mm |
| Width | 570mm |
| Height | 540mm |
| Cubic | 0.3324m³ |
| Weight | 30.00kg |
